2FT 220W Rotatable LED Linear High Bay for Warehouse Lighting
2FT 220W Rotatable LED Linear High Bay for Warehouse Lighting is backordered and will ship as soon as it is back in stock.
2FT 220W Rotatable LED Linear High Bay for Warehouse Lighting is backordered and will ship as soon as it is back in stock.
Description
Description
2FT 220W Rotatable LED Linear High Bay for Warehouse Lighting
The Eco Bright Light 2FT 220W Rotatable LED Linear High Bay delivers 30,800 lumens of powerful 5000K daylight for warehouses, factories, workshops and high-voltage industrial facilities. Two independently adjustable LED modules rotate up to 135°, allowing the light distribution to be optimized for aisles, production floors, storage areas and other demanding high-ceiling applications.
30,800 Lumens
High-output 220W performance provides bright commercial illumination for large industrial spaces.
135° Rotatable Modules
Adjustable LED panels allow the beam direction and coverage pattern to be tailored to the space.
277-480V High Voltage
Designed for high-voltage warehouse, manufacturing and industrial electrical systems.
Sensor-Ready Design
A built-in receptacle supports compatible optional motion or PIR sensors for automated lighting control.
Technical Specifications
| Brand | Eco Bright Light |
| Product Type | 2FT Rotatable LED Linear High Bay Light |
| Input Power | 220W |
| Lumen Output | 30,800 Lumens |
| Luminous Efficacy | 140 lm/W |
| Color Temperature | 5000K Daylight White |
| Input Voltage | 277-480V AC |
| Input Current | 0.79A at 277V / 0.45A at 480V |
| CRI | >80 |
| Beam Angle | 90° Rated Distribution |
| LED Module Adjustment | Rotates Up to 135° |
| LED Technology | High-Brightness Lumileds Chips |
| Housing | Heavy Die-Cast Aluminum Alloy |
| Housing Finish | White Powder-Coated Finish |
| Optical Lens | Frosted Polycarbonate Lens |
| Fixture Dimensions | Approximately 24 × 13.5 × 4.2 in |
| Operating Temperature | -30°C to 50°C |
| Sensor Port | Built-In Receptacle for Compatible Optional Sensors |
| Optional Sensor Detection | Approximately 40-50 ft with Compatible Sensor |
| Mounting Options | Chain/Cable Suspension, 3/4-Inch NPT or Surface Mount |
| HID Replacement | 500-700W Metal Halide or HPS |
| Rated Lifetime | 50,000 Hours |
| Certifications | UL, cUL and DLC |
| Warranty | 5-Year Limited Warranty |
High-Output Industrial LED Lighting
- 30,800-lumen output supports large warehouses and industrial production floors.
- 140 lm/W efficacy delivers strong illumination with efficient LED performance.
- 277-480V compatibility suits high-voltage commercial and industrial facilities.
- 5000K daylight improves visibility around products, machinery and work surfaces.
- CRI above 80 supports accurate recognition of equipment, materials and inventory.
- 90° light distribution directs usable illumination toward the working area.
- Die-cast aluminum housing helps transfer heat away from the LED system.
- Replaces energy-intensive 500-700W metal halide or HPS high bay fixtures.
135° Adjustable LED Modules
Two rotatable LED modules allow the fixture to produce concentrated downward lighting, broader angled coverage or a customized distribution between the two panels. This flexibility is useful for warehouse aisles, production lines, storage racks and irregular industrial layouts where a fixed linear high bay may not provide the required coverage.
Flexible Mounting and Sensor Control
The fixture supports suspended chain or cable installation, compatible 3/4-inch NPT mounting and optional surface mounting. A built-in sensor receptacle allows compatible motion or PIR sensors to be added for occupancy-based control. Optional accessories may include a wire guard, sensor and emergency backup driver, subject to the selected installation method.
Warehouse, Factory and Workshop Applications
Ideal for warehouses, distribution centers, manufacturing facilities, factories, workshops, industrial plants, shopping centers, storage areas and other large indoor spaces using 277-480V electrical systems.
LED Linear High Bay | Rotatable LED High Bay | Warehouse Lighting | LED Warehouse Lights | Industrial High Bay Lighting | Factory Lighting | Workshop Lighting | High Voltage LED High Bay | Commercial High Bay Lights | 480V LED High Bay
Upgrade High-Voltage Industrial Lighting
Choose Eco Bright Light for 220W power, 30,800 lumens, 140 lm/W efficiency, 5000K daylight, 277-480V operation, adjustable LED modules and sensor-ready warehouse lighting.
Package Information
| Package Size | 25.5 × 14.9 × 4.33 in |
| Pack Quantity | 1 Fixture |
| Package Weight | 17.6 lbs |
