30/45/70W Square LED Canopy Light 3CCT for Parking Garages
30/45/70W Square LED Canopy Light 3CCT for Parking Garages is backordered and will ship as soon as it is back in stock.
30/45/70W Square LED Canopy Light 3CCT for Parking Garages is backordered and will ship as soon as it is back in stock.
Description
Description
30/45/70W Square LED Canopy Light 3CCT for Parking Garages
The Eco Bright Light Square LED Canopy Light combines 30W, 45W and 70W selectable power with 3000K, 4000K and 5000K selectable color temperature for versatile parking garage and commercial canopy lighting. Delivering up to 9,100 lumens at 130 lm/W, this fixture features a wide 150° beam, 0-10V dimming and sensor-ready controls for parking structures, underground garages, airport parking areas and commercial buildings.
3 Wattage Selectable
Choose 30W, 45W or 70W to match brightness and energy use to different garage and canopy lighting requirements.
3CCT Selectable
Select 3000K warm white, 4000K neutral white or 5000K daylight for different parking and commercial environments.
150° Wide Beam
Advanced anti-UV PC optics spread illumination broadly across parking bays, drive lanes and low-ceiling areas.
Sensor Ready
Built-in receptacle supports compatible plug-and-play occupancy sensors for intelligent parking garage lighting control.
Technical Specifications
| Brand | Eco Bright Light |
| Product Type | Selectable Square LED Canopy Light |
| Selectable Wattage | 30W / 45W / 70W |
| Lumen Output | 3,900 / 5,850 / 9,100 Lumens |
| Luminous Efficiency | 130 lm/W |
| Color Temperature | 3000K / 4000K / 5000K Selectable |
| CRI | >80 |
| Input Voltage | 120-277V AC |
| Power Factor | 0.9 |
| Dimming | 0-10V Dimmable |
| Beam Angle | 150° Wide Distribution |
| Motion Sensor | Compatible Plug-and-Play Occupancy Sensor Optional |
| Emergency Driver | Optional |
| LED Technology | High-Efficiency Lumileds 2835 LEDs |
| Housing Material | Heavy-Duty Die-Cast Aluminum Alloy |
| Housing Finish | Bronze Powder-Coated Finish |
| Optical Lens | Anti-UV High-Transmission Polycarbonate Optics |
| Fixture Size | Approximately 9.56 × 9.56 × 3.34 in |
| Mounting | Ceiling Mount or 3/4-Inch Conduit Pendant Mount |
| Operating Temperature | -20°C to 45°C |
| Rated Lifetime | 50,000 Hours |
| HID Equivalent | 80W-250W MH/HPS Depending on Selected Wattage |
| Certifications | ETL / cETL / DLC |
| Warranty | 5-Year Limited Warranty |
Selectable Parking Garage LED Lighting
- 30W, 45W and 70W selectable power allows one fixture to meet multiple garage lighting requirements.
- 3,900 to 9,100 lumens provides flexible output for parking structures and commercial properties.
- 130 lm/W efficacy helps reduce energy consumption compared with traditional HID canopy lighting.
- 3000K, 4000K and 5000K selectable CCT simplifies specification for different project environments.
- 150° wide beam provides broad illumination across low ceilings and parking garage drive lanes.
- 0-10V dimming supports adjustable output with compatible commercial lighting controls.
- Optional occupancy sensor can reduce energy use during periods of low traffic.
- Anti-corrosion aluminum housing and anti-UV PC optics support long-term commercial use.
Wide-Beam Lighting with Smart Control
The 150° optical distribution spreads illumination across parking bays, drive lanes and pedestrian areas to help reduce dark spots in low-ceiling environments. Field-selectable wattage and CCT allow installers to configure one fixture for different locations, while the sensor receptacle supports compatible occupancy controls for additional energy savings.
Parking Garage & Commercial Canopy Applications
This square LED canopy light is designed for parking garages, underground parking structures, airport garages, shopping centers, commercial buildings, covered parking areas, building entrances and other low-bay environments requiring wide and uniform overhead illumination.
LED Canopy Light | Parking Garage Lighting | Garage Lights | Parking Structure Lighting | Commercial Canopy Light | Low Bay Lighting | Underground Garage Lighting | Airport Parking Lighting | Building Entrance Lighting
Energy-Efficient HID Replacement
Replace multiple fixed-output metal halide or high-pressure sodium canopy fixtures with one configurable LED solution. Depending on the selected wattage, Eco Bright Light supports compatible 80W-250W HID replacement applications while providing instant LED illumination, selectable CCT, dimming and sensor-ready control.
Upgrade to Selectable Square LED Canopy Lighting
Choose Eco Bright Light for 30W/45W/70W selectable power, 3000K/4000K/5000K CCT, up to 9,100 lumens, 150° wide coverage and intelligent sensor-ready control.
Package Information
| Package Size | 11.5 × 11.5 × 6 in |
| Pack Quantity | 1 Fixture |
| Package Weight | 5.5 lbs |
