The Eco Bright Light 6 Inch Commercial LED Downlight combines three selectable wattages, five selectable color temperatures and universal-voltage operation in one professional recessed fixture. Its high color rendering, diffused low-glare illumination and 0-10V dimming make it ideal for offices, conference rooms, retail stores, restaurants, hotels, schools and commercial corridors. Note: a hardwired junction box is required for installation and is not included.

Technical Specifications

One Fixture for Multiple Commercial Projects

• Three selectable wattages reduce the need to stock separate fixtures.
• Five selectable color temperatures suit office and hospitality projects.
• Up to 1,760 lumens supports general and task-oriented illumination.
• CRI above 90 provides natural-looking merchandise and interior colors.
• Universal 120-277V input supports common commercial electrical systems.
• 0-10V dimming integrates with compatible commercial lighting controls.
• Spring clips provide fast and secure recessed ceiling installation.
• Safety chain adds security when mounting into existing ceilings.

Selectable Wattage and Color Temperature

Set the fixture to 12W for lower-output ambient lighting, 17W for balanced general illumination or 22W for maximum brightness. Choose 2700K or 3000K for hospitality spaces, 3500K for balanced office lighting, 4000K for commercial work areas or 5000K for bright retail and task lighting.

Commercial Recessed Installation

Prepare a compatible hardwired junction box and a ceiling opening of approximately 6 inches. Connect the line-voltage conductors and optional 0-10V dimming leads, select the required wattage and color temperature, attach the safety chain, compress the spring clips and insert the fixture until the trim sits flush with the ceiling.

A hardwired junction box is required and is not included. Verify the supplied cutting template, ceiling thickness, available 5.5-inch clearance and electrical input before installation. Installation should be completed by a qualified electrician.

Office, Retail and Hospitality Applications

Ideal for offices, conference rooms, retail stores, showrooms, hotels, restaurants, schools, universities, apartment common areas, hallways, corridors, reception areas and commercial lobbies.

Commercial LED Downlight | 6 Inch LED Downlight | Wattage Selectable Downlight | 5CCT Downlight | 0-10V Dimmable Downlight | Office Lighting | Retail Lighting | Restaurant Lighting | Hotel Lighting | Recessed Commercial Lighting
